Quick Details

  • Condition: New
  • Type: clay brick machine
  • Brick Raw Material: Clay
  • Processing: Brick Production Line
  • Method: Vacuum Extruder
  • Automatic: Yes
  • Capacity: 7000-8000(pcs/h)
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: Yingfeng
  • Model Number: DZK35
  • Voltage: 220~440V
  • Power: 55kw
  • Dimension(L*W*H): 3.9X1.76X1.69m
  • Certification: ISO9001:2000
  • Warranty: 2 years
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Brick type: Hollow and solid bricks
  • Material of machine: No. 45 steel
  • Extruder type: Vacuum type

Packaging & Delivery

Packaging Details container
Delivery Time Within15 days after recieved down payment





New Machine!DZK35 small red brick making machine/ red brick machine



Product Description



DZK35 Yingfeng brand vacuum clay brick machine is one of our hot sale small models vacuum extruders.

It is widely used in small budget brick owners. It's single stage vacuum extruder which is good to make both solid and hollow bricks, and it can save power as well.  It is our latest product ,we also have own the patent for this product in China. Also, its compact design and auto clutch makes machine operation very easily. Therefore we are selling at least 60 sets per year to over 18 countries.





Note:

 Difference between double-stage vacuum extruder and single-stage vacuum extruder

1.Double stage Vacuum brick extruder can make three kinds of brick, solid brick, porous brick and hollow bricks. To produce different kinds of bricks, usually, only need to fix different brick dies.It is composed of upper stage mixing parts and lower stage extruding parts.

2. Usually Single stage vacuum extruder can produce solid bricks only. It has no upper mixing part, only extruding part.

3.Double stage vacuum extruder has higher capacity, higher vacuum pressure than single stage vacuum extruder.  Also wet bricks made be double stage extruder contain less moisture.



The following is some of brick mould samples which clay red brick machine can produce:

Note: We can provide other different brick mould with different mould sizes according to your requirements. If you can't find the bricks you want to make, please feel free to email us your brick pictures and size. Our email: yingfeng02(at)zzyfmc.com





Raw material to make our red brick machines:

Note: we are responsible for our clients when we choose raw material for our clients,

1. auto oil lubricating system can save labors and it's easy to lubricate extruder's gears and bearings automatically. On the other hand, the lubricating oil can be recycled and to use again, so it can save oils too.

2..For doubles shaft mixer blades, we choose 45 Carbon steel.

3..For roller crusher ,we use high manganese

4.steel.axles, gear and other important spare parts which are made by carbon steel and alloy steel through modulation or quench’s heat treatment procession so as to extend the service life.

5. For hollow brick mould, we use wear resistance ceramic  material as core to ensure longer mould service life.



Production Line

Note:The above production line is based on soft clay,mud,soil.If your material is shale,fly ash,coal Gangue,or with big stones,grass roots,etc,or you want to buy brick carrying cars or robot ,brick stacker, the above line will be adjusted after we get your feedback for your material condition.

                                                   After brick cutting  how to do brick drying and firing
ItemDrying method Firing methodAdvantage and disadvantage
1Natural dryingBuyer Local kiln Very low investment, but may take more labors
2Natural dryingHoffman kiln A little high investment, but may take more labors
3Natural dryingTunnel kilnHigh investment, but takes less labors than Item 2
4Small tunnel dryerHoffman kiln High investment, but takes less labors than Item 2
5Small tunnel dryerTunnel kilnHigher investment, but takes less labors than Item 4
6Big Tunnel dryerTunnel kilnHighest investment, but takes least labors



Our Advantage
 1.We have running brick plant in Asia ,Africa,South America,you can check our machine quality in your local place ,then order from your lcoal places. We can also provide our buyers contact ways,so as to ensure our reality.
2.Provide machine installation video and manual. Even you never use clay brick machine before, once you have our instruction video and manual book, you can handle your project easily. So no worry about future machine breakdown issue.
3. Before our machine is sent to buyer, we would make trial for our each machine 48 hours to ensure each machine quality is perfect no bug.
4. We have responsible despatch department to make sure all small brick machine parts will be packed well ,not be left out.

More choices for you ( Different Model with different capacity ):

Type

Capacity(pcs/h)

Auger Diameter(mm)

Extruding Pressure(Mpa)

Power(KW)

DZK26

2000-3000

260mm

2

22

DZK28

3000-4000

280mm

2

30

DZK30

4000-6000

300mm

2

37

DZK35

6000-7000

350mm

2

55

DZK40

8000-10000

400mm

2

75

DZK45

10000-12000

450mm

2

90



Note: The above capacity is based on Chinese brick size : 240X115X53 mm, if your brick size is different from our brick size, then the capacity will differ .We would send different brick capacity list and different brick machine price list to you once we get your mail to us.



  Our Certificate





Our Workshops





Packaging & Shipping

Clay brick machine delivery for our clients :

1.Each small part of machine would be packed well, also we would arrange engineer to check each machine parts before delivery, so we can ensure buyer can get complete clay brick machine parts. .

2. Some parts will be given soft protection before feeding in the container to make sure all the machine will

be new when arriving at customer hand.

3. Inside the container, we will fix the machine with steel wire,to make sure all the machine will be fixed safety.



Our clay brick machine have been exported to countries such as India, Bangladesh ,Indonesia, Myanmar,

Kazakhstan, Uzbekistan, Russia,Turkmenistan, Mongolia, Nepal, Sudan, South Africa, Uganda,  Mozambique,

Zimbabwe,Congo,Peru, Brazil, Iraq ,Bolivia Mexico,etc. and have won great fame and popularity.

Below is part of our delivery photos for our clients from different countries.



Our Services

Our Brick making machinery  Service :

Yingfeng brick machinery company dedicated to the production of brick machine for more than 25 years,

we are a enterprise that not only supply high quality brick machinery, but also provide full-service for our

clients.Really bring convenient to users and had won the trust of our customers.

We provide the following service:

1. Provide customers with various brick making equipments,

2. provide services like process design, kiln design, workshop design

3. Also, we have a professional team of engineers to do clay brick machine installation, training

workers, imparting technical instruction to our buyers,

4. After brick machine running, we have special aftersale service department to provide spare

parts, machine problem fixing.

5. Professional international after-sale service center available.
6. Successfully running unit abroad for customer’s study and reference.
7. Manual book and videos are available on our website after password provided.

FAQ

Our Running brick production video link

DZK26 simple clay brick production line:

https://www.youtube.com/watch?v=d3ifvCwPU68

JZ300 Non-vacuum clay brick producing line:

http://youtu.be/sjg7GsfcYfk

JKR30 Vacuum clay brick production line with brick separator:

http://youtu.be/TBgEnsWOGyM

JKRL35 Vacuum brick production line with unloader and brick loading cars:

http://youtu.be/IQtzh_pjcxA

JKR40 Vacuum Clay block making machine:

http://youtu.be/jZmoW49xtF8          http://youtu.be/qOCe79N43ns

JKRL45 Vacuum Clay brick production line with auto brick loading cars:

http://youtu.be/3DCR2rR_wYA

JZK50 Vacuum Clay brick producing line with dryer and hoffman kiln:

http://youtu.be/h-m4Vnq8v3c

JKY60 Auto brick production line with tunnel kiln and dryer:

http://youtu.be/8R_XzKkDySU
